Education all in one touch PC 49 inch Pcap Touch Screen Capacitive
Touchscreen Panel
Did you know capacitive technology why so popular ? Because it have
three advantage
Improved Picture
Last but not least, capacitive touchscreen devices have an
exceptional quality picture, thanks to their use of a glass layer.
Resistive touchscreen devices use a plastic layer, which does not
produce this same high-quality picture. If you’re planning to use
the touchscreen device to watch movies, TV shows and/or videos,
you’ll probably want to choose a capacitive model for this reason.
Good Optical Clarity
A capacitive touchscreen sensor consists of a large array of indium
tin oxide (ITO) conductors on one or more layers of glass or
polyethylene terephthalate (PET) plastic.
The good optical clarity and low resistivity of ITO make it the
overwhelming choice for this very sensitive circuit.
Cracked Screens Continue to Function
Let’s hope this never happens, but in the event that your
capacitive touchscreen device cracks, it should continue to
function. Cracked screens are among the most common type of damage
sustained by touchscreen devices. Maybe you drop it on the group,
or perhaps a worker “bumps” into it accidentally. Regardless, minor
cracks shouldn’t interfere with the function of a capacitive
touchscreen device. It will continue to measure the electrical
charge produced by the operator, using this information to
determine where exactly the touch occurred.
Technical parameters
1.Products comply with RoHS standard
2.Euphotic rate of more than 86%
3.For the surface hardness 7H
4.working Voltage: 5.0V The interrupt way The drop-down pulse
5.IC(ILI2301/ILI2302/ILI2510/ILI2312/ILI2511)10point
touch,IOVoltage 3.3V
6.FPC Interface line USB Interface
7.Not specified tolerances +0.2mm
8.COVER LENS Chemical tempered glass
Main Feature
- High image clarity
- Free of drift
- Z-axis pressure recognition
- Strong mechanical strength
- Short response time
- Compact size for easy integration
- Customization available on glass sensorsize, driver, accessories
Specification of Product
| Technical specification |
| Type | Projected touch panel |
| Interface | USB |
| Number of touch point | 10 |
| input voltage | 5V ---- |
| Pressure endurance value | <10g |
| Input | Hand writing or capacitive pen |
| Transmittance | >90% |
| Surface Hardness | ≥6H |
| Usage | The specification is applied to transparent and handwriting input |
| capacitive touch panels |
| Application | It's applied in ordinary electric equipments and automatic office
facilities |
| Cover Lens Specification |
| Pressure Value | 400 ~500 mPA above 6u |
| Ball Drop Test | 130g±2g, 35cm, No damage after the impact at the central area for
once. |
| Hardness | ≥6H Pencil: 6H Pressure: 1N/45. |
| Environment |
| Working temperature and humidity | -10~+60ºC, 20~85% RH |
| Storage temperature and humidity | -10~+65ºC, 20~85% RH |
| Humidity resistance | 85% RH, 120H |
| Heat resistance | 65ºC, 120H |
| Cold resistance | -10ºC, 120H |
| Thermal shock | -10ºC(0.5hour)-60ºC(0.5hour) by 50 cycles |
| Anti - glare Test | Incandescent lamp (220V,100W) , |
| operating distance over 350mm |
| Altitude | 3,000m |
| Working Environment | Directly Under sunlight ,indoor and outdoor |
| Software(Firmware) |
| Scanning | Auto full screen scanning |
| Operate system | Win 7,Win 8,Win10, Andriod,Linux |
| Calibration tool | Precalibrated & Software can be download in CJTouch Website |
Picture of Product
Technical Drawing
